Narrow Pitch Connectors​
Selection map​

Board to FPC, Board to Board

connectors_image

Easily select connectors from Panasonic Industry recommended series.​

Feel Free to contact us for technical questions.​

If you want to search by more detailed specifications, click here.

Please choose the connector type.​

Narrow Pitch Connectors

Please select the terminal pitch.​

Terminal pitch　 0.35mm

Recommended series part numbers can be selected from the table.​

Series​ Mated Height​ Short width Rated current of
power terminal		 Number of pins 4～20 Number of pins 24～60 Number of pins 64～100
4 6 10 12 16 20 24 26 30 34 40 44 50 54 60 64 70 80 100
R35K 0.6mm 1.3mm 3.0A/pin contact
  High current​
✓ ✓ - - - - - - - - - - - - - - - - -
R35 0.6mm 1.7mm 5.0A/pin contact
  High current​   		- - ✓ - ✓ ✓ ✓ ✓ ✓ - ✓ - ✓ - ✓ - - - -
S35 0.6mm 1.7mm — - ✓ ✓ ✓ ✓ ✓ ✓ - ✓ ✓ ✓ ✓ ✓ ✓ ✓ - - - -
A35UH 0.6mm 2.2mm 5.0A/pin contact
  High current​   		- - ✓ ✓ ✓ ✓ ✓ - ✓ ✓ ✓ ✓ ✓ ✓ ✓ - ✓ - -
S35 0.8mm 1.7mm — - - - ✓ - - ✓ - - ✓ - ✓ - - - - - - -
A35S 0.8mm 2.5mm — - - ✓ ✓ ✓ ✓ ✓ - ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
A35P 0.8mm 2.5mm 1.5 A/pin contact×4 pin* or​
1.25 A/pin contact×8*
  High current​   		- - ✓ ✓ ✓ ✓ ✓ - ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓

* : When using the signal contact as a power contact

Terminal pitch　 0.4mm

Recommended series part numbers can be selected from the graph.​



Terminal pitch​　 0.5mm

Recommended series part numbers can be selected from the graph.​



Battery Connectors

Connector series can be selected from the table.​


 Series
Short width
Mated height
No. of pins
Rated current
2.4mm
0.6mm/0.8mm
6
[ Power contact ] 3.0A/pin contact
[ Signal contact ] 0.3A/pin contact
B02
2.2mm
0.7mm
8
[ Power contact ] 5.0A/pin contact
[ Signal contact ] 0.3A/pin contact

Narrow Pitch RF Connectors​

Connector series can be selected from the table.​


Series
Short
width
Mated
height
No.
of pins
Rated current
2.44mm
0.6mm
10
[ Power contact ] Max. 1.0 A / pin contact x 2 pin contacts
[ Signal contact ] Max. 0.3 A / pin contact x 8 pin contacts
B02
2.48mm
0.65mm
6
Max. 0.3 A / pin contact x 6 pin contacts
Max. 1.0 A / pin contact x 2 pin contacts
(2 pin contacts other than high frequency signal contacts)
Feel Free to contact us for technical questions.​
